Description

Economical 55″~ 82″ Line up Full-HD Interactive Electronic Board.

    • Smart exterior design.
    • Full HD 1080P LED panel & 4K UHD support.
    • Infrared beam with 10 point multi touch support.
    • Customer writing S/W PowerACE.(blackboard & pointer mode, draw, write and erase)
    • Windows 10 Professional giving you access to thousands of touch-enabled apps.
    • AG coated tempered glass.

Specifications

55INCH 65INCH 75INCH 86INCH
Panel Active Display size 1209.6(H)
X
680.4(V)
1428.48(H)
X
803.52(V)
1649.66(H)
X
927.936(V)
1895.04(H)
X
1065.96(V)
Panel Resolution 1920 x 1080 (FHD) 3840 x 2160 (UHD) 3840 x 2160 (UHD) 3840 x 2160 (UHD)
Brightness 300 cd/㎡ 390 cd/㎡ 410 cd/㎡ 470 cd/㎡
Contrast ratio 1200 : 1 1100 : 1 1200 : 1 1400 : 1
Response time 6ms 6ms 8ms 5ms
Viewing angle 178° / 178° 178° / 178° 178° / 178° 178° / 178°
Touch system Detection method Infrared Beam
Touch Tool Finger, gloved hans or any other pointer
Number of touch 10point Multi
Supported OS Win XP, Windows7, Windows8, Windows10
Connectivity Video input(analogue) Display Port(DP) x 1
Video input(digital) HMDI x 3
Speaker 10W x 2
Dimensions Dimensions(mm) 1278(W)
X
748(H)
X
108.6(D)
1475.5(W)
X
848.5(H)
X
109(D)
1703.9(W)
X
979.9(H)
X
97.9(D)
1940(W)
X
1111(H)
X
98(D)
Weight (Kg) 40kg 50kg 70kg 90kg
Power Supply AC 100V ~ 240V, 50/60Hz
